The Perfect Fit ™ for Aircraft Flight Decks The EFI-890R Advanced Flight Display offers flexibility for installation as a stand-alone Primary Flight Display (PFD) or Multi-Function Display (MFD), as well as a fully integrated PFD/Navigation Display (ND) cockpit system. The unit is optimally sized, featuring a lightweight, compact housing while offering a large, 8.9-inch diagonal LCD display. The high-resolution, high-contrast display provides superior readability throughout a full range of ambient lighting conditions including bright sunlight and dim nighttime environments. Extremely wide viewing angles are also accommodated. A unique LED backlight system with reduced power requirements produces a lower unit operating temperature for superior reliability. This LED backlight system produces brighter, clearer displays with improved color uniformity. The EFI-890R replaces ADI, HSI, Radar Indicator, Altimeter, VSI, RMI and Airspeed Indicators with PFD and ND large multi-format displays.

The dedicated Engine Display available in certain aircraft installations replaces the existing individual electromechanical instruments with a single screen, dual-channel redundancy. Versatile Retrofit and Forward-fit Applications Featuring an adaptable design, the EFI-890R is a proven solution for retrofit an forward-fit applications in over 40 aircraft types. It is certified for a full range of platforms, meeting certification requirements for Part 23, 25, 27 and 29 operators worldwide. With interface capabilities for numerous flight deck instruments, its versatile design supports direct inputs from a multitude of analog and digital aircraft systems from autopilots and flight directors to radars and Terrain Awareness and Warning Systems (TAWS). For operators, this eliminates the cost of replacing existing systems or the need for additional external symbol generators resulting in significant cost-savings.

Start studying Casa 212 Systems Ryan Air. Learn vocabulary, terms, and more with flashcards, games, and other study tools.

The EFI-890R offers a solution to best match your aircraft and your operational requirements. Hardware Bezel Size: 7.84 in. W Depth: 9.79 in. (back of bezel to rear of connector) Image Size: 6.3 in. Diagonal) Weight: 10.4 lbs.

Mounting: 4-point corner bolt-mounted from front Faceplate Color: Gray or Black Display: Active Matrix Color LCD with LED backlight system Viewing Angle: +60 / -60 deg. Horizontal, +45 / -10 deg. An array of Dzus-mounted control panels support 1-, 2-, 3-, 4- and 5-display configurations with dedicated/shared control. Course/Heading Control Panel is available in single or dual control format. It controls setting of the heading reference bug and short range NAV source course, with a “push to sync” function available for both. Reference Select Control Panel supports setting of Speed and Altitude Reference Bugs on the PFD, Altitude Preselect and airspeed/altitude units of measure.

Available in either a single or dual control format. PFD Combined Display Control Panel provides for NAV/BRG source select, baro altitude/minimums select, RA / DA toggle, ADC revert, attitude/heading revert, display revert, and source transfer for the on-side PFD and ND / MFD. Also provides for selection of terrain, weather, and traffic for the on-side PFD. It incorporates ATT/HDG and ADC Revert buttons, eliminating the need for separate switches in the installation.

This control panel is also available in a vertical format. Display and Radar Control Panel provides for weather radar range, antenna tilt, and mode control for compatible weather radar systems. It also provides for traffic, terrain, and external video selection for the ND/MFD. Display Control Panel provides for traffic, terrain, weather and external video selection for the ND/MFD.

Natops Flight Manual

Does anyone have a copy of the CH-53E/MH-53E NATOPS manual in PDF format? I have a copy, but it is somewhat blurred and I would like to have a clean copy. I know they are available online for purchase via eflightmanuals.com and rareaviation.com, but I would like to offer something from my massive list of manuals in exhange for a copy of the CH-53E/MH-53E manuals. Please contact me at if you are interested in trading manuals. Please send a list of available manuals and I will send you a copy of my list.
